HypaLUME 110/230 V AC

Extremely robust, extremely strong: The HELLA HypaLUME 110/230 V AC Heavy Duty LED Flood Light work lamp has been specially developed for applications where maximum load capacity and very high light output are required, such as mining.


The fully sealed and totally corrosion-protected work lamp produces an outstanding 28,000 lumens at 100-240 volt AC input. Current consumption is 300 watts. Thanks to the locking and the high-quality heavy-duty aluminium housing, as well as the lens made of the durable, high-tech material Grilamid®, the HypaLUME 110/230 V AC can withstand even the toughest operating conditions and adverse weather conditions. It is optimally protected against dust, water, vibrations, shocks, and impacts, as well as salt and chemicals.


The durable, maintenance-free LED technology ensures optimum, uniform illumination, depending on the variant, in the close-range, long-range, and with extra-wide radiation. The bright, daylight-like light colour is particularly easy on the eyes.


Upright or pendant surface mounting is possible.

Product Advantages

  • Specially developed for applications with extremely high light requirements
  • Perfectly suited for the toughest operating conditions
  • Fully sealed and corrosion-protected
  • Also available with amber cover lens, for improved visibility in dust, fog, or snow

Video of the HypaLUME extreme testing

Technical Data

Operating voltage Multi-voltage (100-240 V AC)
Rated voltage 110 V AC/ 230 V AC
Power consumption max. 300 W
Light output 28,000 lm
Light source LED
Colour temperature

Standard: 5,700 K
Amber: 2,500 K


Housing: premium aluminium with non-stick coating
Cover lens: impact-resistant and chemical-resistant Grilamid®


Standard: 15,590 g
Amber: 17,000 g

Temperature range -40 °C to +50 °C
Protection class IP 6K7, IP 6K6
EMC protection RCM, FCC
Mounting Upright and pendant
Connection Wieland RST Mini connector - 16 A, 2,000 mm single pluggable sheathed cable is included in delivery

Program Overview

Variant Cover lens colour Illumination Part number
HypaLUME 110/230 V AC Clear Close-range illumination 1GJ 958 334-011
Long-range illumination 1GJ 958 334-021
Extra-wide illumination 1GJ 958 334-031
HypaLUME 110/230 V AC Amber Amber Close-range illumination 1GJ 958 334-111
Long-range illumination 1GJ 958 334-121
Extra-wide illumination 1GJ 958 334-131
