K LED Rebelution Revolutionary Technology
K LED Rebelution Revolutionary Technology
K-LED Rebelution sets new standards with its minimalist design and patented LED technology. The circumferential light strip generates a strong warning signal – despite its compact design and minimal light exit area.
- Design beacon that impresses both technologically and visually
- Legally protected design
- Innovative light exit area
Revolutionary lighting design with maximum warning effect
K-LED Rebelution clearly stands out from conventional beacons thanks to its unique, futuristic design without a traditional dome. The ring-shaped light strip provides a powerful double flash or rotating signal and meets the most stringent EMC and protection class requirements. Innovative LED technology ensures durable performance – even under extreme operating conditions.
Technical Sheet
K-LED Rebelution
- 2XD 455 255-001
- fulfils SAE standard J845 Class 2
- fulfils EMC/CISPR standard Class 5
- Voltage 12 V, 24 V
- Registration Type ADR/GGVS approved , SAE approved
- Light Function with flashing warning signal , with rotating warning signal
- Mounting Type mounting , Bolted
- Prot.type (IP Code) IP6K7 , IP6K9K
- fulfils ECE standard R10 , R65 , TA1
- Light Design LED
|
K-LED Rebelution
|
|
|---|---|
| 2XD 455 255-001 | |
| fulfils SAE standard | J845 Class 2 |
| fulfils EMC/CISPR standard | Class 5 |
| Voltage | 12 V, 24 V |
| Registration Type | ADR/GGVS approved , SAE approved |
| Light Function | with flashing warning signal , with rotating warning signal |
| Mounting Type | mounting , Bolted |
| Prot.type (IP Code) | IP6K7 , IP6K9K |
| fulfils ECE standard | R10 , R65 , TA1 |
| Light Design | LED |
| Lamp Type | LED |
| Height | 60 mm |
| Outer Diameter 1 | 149 mm |
| Number of LEDs | 32 |
| Light colour | yellow (amber) |
| Plug Type | Blade Terminal |
| fulfils test standard | RCM |
| Lens Colour | yellow (amber) |
| Housing Colour | black |
| Flash rate per minute | 124 |
| Power consumption | 38 W |
| Housing material | Aluminium |
| Temperature range from | -40 °C |
| Temperature range to | +60 °C |
| Cable Length | 150 mm |
| Diffusing Lens Material | PC (Polycarbonate) |
| Weight | 735 g |
| Quantity | 1 |
| Supplementary Article/Supplementary Info 2 | Electromagnetic Compatibility (EMC) |
