S90 – disc horn | Strong sound
S90 – disc horn | Strong sound
S90 combines powerful sound propagation with precise sound radiation – ideal for an effective warning effect in any traffic situation. Rugged, functional and to the point.
- Strong and bundled sound radiation
- Fully shaped oscillator for optimum sound performance
- Reliable horns in original equipment manufacturer quality from a leading global supplier
Essential companions
Horns are pivotal for road safety – not just mandatory, but a crucial factor when it counts. Every second counts in critical situations – that's why our powerful horns with their clear, penetrating sound make sure that you can reliably draw attention to yourself. Rely on maximum operational reliability and quality when it really matters.
Technical Sheet
S90 Set
- 3AM 922 000-971
- Voltage 12 V
- Power consumption 42 W
- Sound Level 111 dB(A)
- Frequency Range 350 Hz, 415 Hz
- Charging Rate 3,5 A
- Prot.type (IP Code) IP65
- fulfils ECE standard R28
- Registration Type ECE approved
- Signal High Tone , Low Tone
S90 Single 350HZ
- 3AL 922 000-951
- Voltage 12 V
- Power consumption 42 W
- Sound Level 111 dB(A)
- Frequency Range 350 Hz
- Charging Rate 3,5 A
- Prot.type (IP Code) IP65
- fulfils ECE standard R28
- Registration Type ECE approved
- Signal High Tone
|
S90 Set
|
S90 Single 350HZ
|
|
|---|---|---|
| 3AM 922 000-971 | 3AL 922 000-951 | |
| Voltage | 12 V | 12 V |
| Power consumption | 42 W | 42 W |
| Sound Level | 111 dB(A) | 111 dB(A) |
| Frequency Range | 350 Hz, 415 Hz | 350 Hz |
| Charging Rate | 3,5 A | 3,5 A |
| Prot.type (IP Code) | IP65 | IP65 |
| fulfils ECE standard | R28 | R28 |
| Registration Type | ECE approved | ECE approved |
| Signal | High Tone , Low Tone | High Tone |
| Housing Colour | red/black | red/black |
| Quantity | 2 | 1 |
| Operating Mode | Electric | Electric |
| Ø | 90 mm | 90 mm |
| Temperature range from | -40 °C | -40 °C |
| Temperature range to | +90 °C | +90 °C |
| Mounting Type | Flat Plug-in Connector | Flat Plug-in Connector |
| Supplementary Article/Supplementary Info 2 | with E quality seal | with E quality seal |
| Search the web | Search the web | |
|
|
|
