BST warning lamp

Truck Construction machinery Car

BST warning lamp

The HELLA BST warning lamp combines innovative LED technology with a compact design for a reliable and powerful signalling effect. Thanks to variable installation options and flashing patterns with synchronisation capability, it is ideal for a wide range of professional applications.

Various flashing patterns
Slim, compact design enables simple installation
Can be synchronised with 2 or with several units

Technical details

Sound test

Ambient noise On Off

Search the web

Compact fixed-installation warning lamp with powerful LED signalling effect

The HELLA BST fixed-installation warning lamp with six high-performance power LEDs offers outstanding visibility and an attention-grabbing warning signal. The precise optics ensure uniform light distribution. With five different flashing patterns, its synchronisation capability for several units make it the ideal solution for a wide range of vehicle applications.

Technical Sheet

BST

2XD 012 160-851
Mounting Type Screw Connection
Lamp Type LED
Light Design LED
Voltage 12 V, 24 V
Fitting Position frontal sided
Length 127,45 mm
Height 28 mm
Width 127 mm
Depth 17 mm

Overall Height 17,61 mm

Light Function with flashing warning signal

Light colour yellow (amber)

Number of LEDs 6

Plug Type open cable ends

Prot.type (IP Code) IPX9K , IP5K4K , IP6K9K

fulfils ECE standard R10 , R65 , XA1

SVHC 7439-92-1; Lead

Registration Type ECE approved , ADR/GGVS approved , SAE approved

fulfils SAE standard J845 Class 1

fulfils EMC/CISPR standard Class 5

Fastening Type for horizontal fastening

Reverse polarity protection Yes

Power consumption 14 W

Diffusing Lens Material PC (Polycarbonate)

Housing Colour black

LED colour yellow (amber)

Lens Colour Crystal clear

Cable Length 150 mm

Housing material Aluminium

Temperature range from -40 °C

Temperature range to +60 °C

Weight 192 g

Supplementary Article/Supplementary Info Observe the national mounting, install. and operat. regs.

Quantity 2

Special Purpose Vehicle for special-purpose vehicles
