SMART Cornering Light

Pretty smart: The HELLA SMART Cornering Light ensures increased safety when turning in poorly lit working environments without natural daylight.


The smart HELLA LED dynamic cornering light switches on automatically when corresponding steering movements are made, helping drivers to detect obstacles in good time. This effectively prevents collisions with objects or slipping on precipices. Thanks to the SMART Cornering Light, both operational safety for all involved and comfort are increased through better perception of the surroundings.


The SMART Cornering Light includes a set of two LED lamps and an intelligent control unit. The lamps are mounted on the front left and right of the vehicle. The control unit communicates with the lamps and activates the left or right lamp depending on the vehicle movement when turning. Depending on the variant, the work lamps generate 2,700 (RokLUME C180) or 4,400 (RokLUME 280N) lumens of light output with a maximum consumption of 30 watts (RokLUME C180) or 50 watts (RokLUME 280N). The work lamps are dustproof, waterproof, and high-pressure jet cleaner resistant. They are ECE- and RCM-approved.


The dynamic cornering light can be retrofitted quickly and easily.

Product Advantages

  • Improved illumination when turning the vehicle left or right
  • For more safety and comfort
  • Easy retrofitting

Video of the SMART Cornering Light

Technical Data

  RokLUME C180 set RokLUME 280N set
Operating voltage Multi-voltage (9-32 V)
Rated voltage 12 V/ 24 V
Power consumption max. 30 W per work lamp max. 50 W per work lamp
Light output 2,700 lm per work lamp 4,400 lm per work lamp
Light source LED
Colour temperature 5,000 K
Material Housing: die-cast aluminium with NanoSafe coating
Cover lens: glass
Housing: die-cast aluminium with NanoSafe coating
Cover lens: impact-resistant and UV-resistant plastic
Weight 2,089 g 3,800 g
Temperature range -40 °C to +50 °C
Protection class Work lamp: IP 6K9K, IP 6K7
Control unit: IP 5K4K, IP 5K9K
EMC protection ECE-R10, RCM
Mounting Upright
Connection Cable (incl. all cables for installation)
Manufactured in Austria/Germany

Program Overview

Variant Part number
SMART Cornering Light RokLUME C180 set 1G0 996 476-801
SMART Cornering Light RokLUME 280N set 1GA 995 606-801



Description Part number
SMART Cornering Light adapter cable (6 m) and DEUTSCH DT 2 pin connector set 8KB 994 246-071
