Wide-angle mirror for agricultural and construction machinery

Everything always at a glance: The HELLA wide-angle mirror for agricultural and construction machinery is specially designed to meet the needs of drivers of special vehicles such as construction machinery, front loaders, tele-handlers, combine harvesters, crop sprayers, etc. The mirror thus offers a wide range of applications in demanding work situations, e.g. on construction sites or in agriculture. The fully utilized glass radius of 315 mm and the maximized curvature of the mirror surface significantly increase the driver’s indirect field of vision, thus enhancing operational safety.



The compact, slim design with a reduced bezel allows for optimal integration of the mirror into modern vehicles. The highly corrosion-resistant mirror glass as well as the stable, UV-resistant plastic housing made of PP (PP=polypropylene) ensures a long service lifetime and high resilience.

Product Advantages

  • Reduced weight and optimized ergonomics due to slim housing and minimized bezel
  • PP housing with high UV stability
  • Modern, aerodynamic style in line with today’s vehicle designs
  • Surface with ultra-high corrosion resistance

Technical Data

Surface mounting

Vertical and horizontal, large adjustment range in the

x and y-positions for optimum visibility,

rotatable around z-axis

Support rod

Ø 18 to 24 mm

Housing

PP housing with high UV stability
Mounting Pre-assembled screws for easy mounting

Program Overview

Variant Part number Packaging unit
Wide-angle mirror for agricultural and construction machinery 8SB 015 039-081 1
Wide-angle mirror for agricultural and construction machinery 8SB 015 039-087 12
