B133 – 24 V Disc Horn | Super Tone
B133 – 24 V Disc Horn | Super Tone
This heavy-duty disc horn delivers HELLA’s signature Super Tone with exceptional volume and clarity. Its robust black housing and protective grille ensure durability, while high power output guarantees reliable signaling for maximum road safety in demanding conditions.
- Signature Super Tone from HELLA
- Black housing and protective grille
- High power wattage 84 W
- With 6.3 mm blade terminal contacts, open
- Bracket on horn for M10 fixing screw
Essential companions
Horns are pivotal for road safety – not just mandatory, but a crucial factor when it counts. Every second counts in critical situations – that's why our powerful horns with their clear, penetrating sound make sure that you can reliably draw attention to yourself. Rely on maximum operational reliability and quality when it really matters.
Technical Sheet
SUPER TONE HORN 2 UNITS 24V SW
- 3AG 003 399-101
- Voltage 24 V
- Power consumption 84 W
- Sound Level 110 dB(A)
- Frequency Range 375 Hz, 500 Hz
- Charging Rate 3,5 A
- Prot.type (IP Code) IPX9K , IPX7
- fulfils ECE standard R28
- Registration Type ECE approved
- Housing Colour black
|
SUPER TONE HORN 2 UNITS 24V SW
|
|
|---|---|
| 3AG 003 399-101 | |
| Voltage | 24 V |
| Power consumption | 84 W |
| Sound Level | 110 dB(A) |
| Frequency Range | 375 Hz, 500 Hz |
| Charging Rate | 3,5 A |
| Prot.type (IP Code) | IPX9K , IPX7 |
| fulfils ECE standard | R28 |
| Registration Type | ECE approved |
| Housing Colour | black |
| Signal | High Tone , Low Tone |
| Quantity | 2 |
| Operating Mode | Electric |
| Overall Height | 135 mm |
| Width | 125 mm |
| Ø | 123 mm |
| Depth | 85 mm |
| Special Purpose Vehicle | for special-purpose vehicles |
| Temperature range from | -40 °C |
| Temperature range to | 75 °C |
| Mounting Type | Flat Plug-in Connector |
| Supplementary Article/Supplementary Info 2 | with moisture protection , with rubber grommet , without E quality seal , with condenser |
| Search the web | |
|
|
